6.5 Weatherby RPM 143 Grain Hornady ELD-X~100% Hand-Loaded!!

6.5 Weatherby RPM 143 grain Hornady ELD-X- The 6.5 WBY RPM is based on a lengthened version of the existing 284 Winchester. This cartridge has a rebated rim, making it compatible with standard 30-06 bolt faces and reloading equipment. However, the large body diameter, low body taper, and 35-degree shoulder mean that case capacity is greatly increased, leading to higher velocities. In addition, bullet innovation in the 6.5mm category is highly efficient with less drop and wind deflection than many heavier calibers. All these details culminate into a cartridge that delivers 1,500-foot pounds of energy at 500 yards capable of ethically taking big game animals across the globe.

Joseph von Benedikt of Shooting Times, writes: The all-new 6.5 Weatherby Rebated Precision Magnum (WBY RPM) cartridge is a vast departure from classic Weatherby design. The 6.5 WBY RPM has no belt, no double-radius shoulder, and no freebore. It’s still a hotrod, but that’s about all it has in common with its traditional belted-magnum, Venturi-shouldered, generously freebored ancestors.

The cartridge has a steep, 35.25-degree shoulder, nearly parallel sides, and a rebated rim. For those of you familiar with the 6.5-284 Norma, imagine a stretched-out version that makes the most of a long rifle action, provides magnum 6.5mm ballistics, and is compatible with a standard 0.473-inch-diameter (.30-06 size) boltface.

So, what inspired this dramatic departure from traditional Weatherby engineering? The 6.5 WBY RPM cartridge was designed for a new, sub-five-pound mountain rifle built on a titanium version of the company’s slender six-lug Mark V action. Titanium is another first for Weatherby. There are only a couple of centerfire rifle actions in existence that are this slender, and before the 6.5 WBY RPM, no magnum cartridge fit and functioned in any of them because the boltfaces of petite actions are not big enough in diameter to handle traditional magnum cartridge case heads. Thus, the rebated rim of the 6.5 WBY RPM.

Choice Ammunition has taken our 100% hand-loading techniques and produce an extremely accurate, highly dependable round for the 6.5 PRC in this load. Our loading tolerances are only matched by passionate hand-loaders in their own loading rooms. Consistent seating depths, powder charges and proprietary formulas of Choice Ammunition, make this 143 Grain Hornady ELD-X round the best you can buy on the commercial market today.

The Bullet-

The Heat Shield tip of the Hornady ELD-X bullet defies the effects of aerodynamic heating and retains its shape to provide a perfect meplat (tip) that is always the same shape. A streamlined secant ogive with optimum boattail design, plus the highly concentric AMP bullet jackets, combined with the patent pending Heat Shield tip creates a supremely accurate, high BC match bullet. ELD-Match bullet BCs are measured with Doppler radar and corrected to standard atmospheric conditions. With high velocity, 0-400 yard impact, the bullet continually expands throughout its penetration path. The thick shank of the jacket and high Interlock ring keep the core and jacket together providing 50-60% weight retention. Upon low velocity, 400+ yard impacts, the Heat Shield tip drives backward into the bullet to initiate expansion. Exhibiting conventional expansion with a large mushroom and 85-90% retained weight the bullet provides deep penetration and large wound cavities.

• Velocity 3,033 fps
• 100% Hand Loaded
• G-1 BC 0.625
